| Model | ET95 / ET95-ES | ET110 / ET110-ES | ET120 / ET120-ES | ET140DI / ET140DI-ES | ||||
| Type | Water-Cooled, 4-Stroke, Horizontal, Diesel Engine | |||||||
| No of Cylinder (unit) | 1 | |||||||
| Cylinder Bore x Stroke (mm x mm) | 86 x90 | 92 x90 | 94 x90 | 97 x96 | ||||
| Displacement Volume (cc) | 522 | 598 | 624 | 709 | ||||
| Maximum Power hp/rpm (kW/rpm) |
9.5/2400(6.99/2400) | 11/2400(8.09/2400) | 12/2400(8.8/2400) | 14/2400(10.3/2400) | ||||
| Continuons Rated Power hp/rpm (kW/rpm) |
8.5/2400(6.25/2400) | 10/2400(7.35/2400) | 11/2400(8.09/2400) | 12.5/2400(9.19/2400) | ||||
| Sepcific Fuel Consumption at Continuons Rated Power g/kWh( g/hph ) |
≦286 ( 210 ) | ≦257 ( 188 ) | ||||||
| Compression Ratio | 21:1 | 18:1 | ||||||
| Valve Clearance (mm) | 0.195-0.235 | |||||||
| Max torque (kgf.m/rpm) | 29.4/1600 | 34.5/1600 | 38.2/1600 | 50/1600 | ||||
| Cooling Water Capacity (L) | 2.1 | |||||||
| Fuel Tank Capacity (L) | 11 | |||||||
| Lubrication Oil Capacity (L) | 2.8 | |||||||
| Fuel | Light Diesel Oil (SAE No.2-D) | |||||||
| Lubrication Oil | SAE 40 API CF | |||||||
| Combustion System | Swril Chamber | Direct Injection | ||||||
| Cooling system | Pressurized Radiator type | |||||||
| Lubricating system | Trochoid Pump | |||||||
| Air Cleaner Type | Wet-Type (Oil Bath - Type) | |||||||
| Starting System | Double Speed Hand Starting / The ES Model Feature an Electric Starter | |||||||
| Direction of Rotation | Clockwise as Viewed from The Starting Handle (Right Hand Rotation) | |||||||
| Battery (ES Model Only) | 12 Volt Battery (Minimum 30 amperes- hour/Ah) | |||||||
| N.W(kg) | 105/110 | 110/115 | 112/117 | 116/121 | ||||
| Packing dimension(L*W*H) | 830*380*630mm | |||||||
